Supplier’s
name or trade mark: CHANGZHOU TOPKING
INTERNATIONAL TRADE CO.LTD
|
Supplier’s
address :
Room 409, No.1 Fuchen Building No.8 Taihu East
Road, Changzhou, Jiangsu,
China
|
Model identifier:G125 6W
|
Type
of light source:LED
|
Lighting
technology used:
|
LED
|
Non-directional
or directional:
|
NDLS
|
Mains
or non-mains:
|
MLS
|
Connected
light source (CLS):
|
NO
|
Colour-tuneable
light source:
|
NO
|
Envelope:
|
NO
|
High luminance
light source:
|
NO
|
|
|
Anti-glare shield:
|
NO
|
Dimmable:
|
NO
|
Product parameters
|
Parameter
|
6W
|
Parameter
|
2700K
|
General product parameters:
|
Energy consumption in on-mode (kWh/1 000 h)
|
6W
|
Energy
efficiency class
|
F
|
Useful
luminous flux (Φuse),
indicating if it refers to the
flux in a sphere
(360°), in a wide cone
(120°) or in a narrow cone (90°)
|
600Lm
|
Correlated
colour temperature, rounded to the nearest 100 K, or the range
of correlated colour temperatures, rounded to the nearest
100 K, that can be set
|
2700K
|
On-mode power (Pon), expressed in W
|
6W
|
Standby
power (Psb), expressed
in W and rounded to the second
decimal
|
N/A
|
Networked
standby power (Pnet) for CLS, expressed in W and rounded to the second
decimal
|
NO
|
Colour
rendering index, rounded to the nearest integer, or the range of CRI-values that can be set
|
80
|
Outer dimensions
without separate control gear, lighting control parts and non-lighting
control parts, if any (millimetre)
|
Height
|
125 mm
|
Spectral
power distribution in the range 250 nm to 800 nm,
at full-load
|
|
Width
|
125 mm
|
Depth
|
170mm
|
Claim
of equivalent power
|
YES
|
If
yes, equivalent power (W)
|
48
|
|
|
Chromaticity
coordinates (x and y)
|
0.485,0.427
|
Parameters
for directional light sources:
|
Peak
luminous intensity (cd)
|
N/A
|
Beam
angle in degrees, or the range
of beam angles that can be set
|
N/A
|
Parameters
for LED and OLED light sources:
|
R9 colour rendering index value
|
2
|
Survival
factor
|
0,90
|
the lumen maintenance factor
|
0.93,5
|
|
|
Parameters
for LED and OLED mains light sources:
|
displacement
factor (cos φ1)
|
0,5
|
Colour
consistency in McAdam ellipses
|
6
|
Claims
that an LED light source replaces a fluorescent light source without integrated ballast of a particular wattage.
|
NO
|
If
yes then replacement claim (W)
|
|
Flicker
metric (Pst LM)
|
1
|
Stroboscopic
effect metric (SVM)
|
0,4
|
